| GENERAL |
| Type: | Amateur multimode radio decoder |
| CPU: | ? |
| System ROM: | ? KB |
| System RAM: | ? KB |
| Computer ports / Speed: | None |
| Power supply: | 11-14 VDC |
| Current drain / power consumption: | Less than 700 mA |
| Dimensions (W*H*D): | 260*75*185 mm (10.24*2.95*7.28") |
| Weight: | 1.5 Kg (3.31 lb) |
| Other features: |
2*40 character LCD display. RF/Video output. Centronics printer port.
|
|
|
|
|
| RADIO COMM'S SECTION |
| Modes: |
RTTY
CW
ASCII
AMTOR / SITOR
|
| GPS / APRS functions: | No |
| Mailbox: | No |
| Radio ports: |
1
|
| Data rate over radio: | 45-300 bd |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1988-19xx (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
