| GENERAL |
| Type: | Amateur HF transceiver |
| Frequency range: |
TX: 10 / 11 / 12 / 15 m + MARS
RX: 14-30 MHz
|
| Tuning steps: | 1-50 kHz selectable in 1 kHz steps |
| Frequency stability: | ±2 ppm @ -10° to +60°C (14° to 140°F) |
| Mode: | AM / FM / SSB / CW |
| Channels / memory management: |
None
|
| Repeater shift / offset: | -100 kHz |
| Power supply: | 9-15 VDC |
| Current drain / power consumption: | RX: 42 mA @ 12 VDC (With signal)
TX: Max 2 A @ 12 VDC |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 90*60*150 mm (3.5*2.4*5.9") |
| Weight: | 300 g (10.6 oz) |
| Other features: | CTCSS/PL. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 455 KHz
|
| Sensitivity: | Better than 1.0 uV (12 dB S/N) |
| Squelch sensitivity: | 0.4 uV (Threshold) |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 800 mW at 10% distortion / 8 ohm |
| External speaker connector: | RJ45 |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Up to 7 W @ 12 VDC
|
| Modulation system: | SDR I/Q |
| Max FM deviation (Factory set): | ±2.0 kHz |
| Spurious emissions: | Better than -43 dB |
| Microphone impedance / connector: | 2.2 Kohm (Electret) / RJ45 |
| Microphone input level: | 10 mVpp |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Germany, 2018-2022 (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
ZFX-240
ZFX-300
ZFX-310
ZFX-3000
|
Speaker-microphone (As supplied)
Protective cover / stand
Carrying pouch with Molle system, coyote tan
External wide-band tune-free antenna 20-30 MHz
|
|
