| GENERAL |
| Type: | Military VHF transceiver |
Frequency range
depending on version: |
MWP: 66-88 MHz (Any 5 MHz segment according to alignment)
HWP: 138-174 MHz (Any 10 MHz segment according to alignment)
|
| Tuning steps: | Channelized. Programmable in 12.5 and 25 KHz increments. |
| Frequency stability: | ±0.0005% @ -30 to +60°C (-22 to +140°F) |
| Mode: | FM |
| Channels / memory management: |
16 regular
Scanning
|
| Duplex shift / offset: | Programmable |
| Power supply: | 10.8 VDC (NiCd battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / Threads |
| Dimensions (W*H*D): | 80*205*55 mm (3.15*8.07*2.16") |
| Weight: | 960 g (2.12 lb), with battery and antenna |
| Other features: |
CTCSS/PL. Waterproof and submersible.
Multi-tone selcall option.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.35 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 500 mW at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
MWP
High: 2 W
Low: 500 mW
HWP
High: 5 W
Low: 1 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1999-200x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BC-125
FP-1
HMS-8
MC-4
NP-18
RA-12
VOX-100
|
Desktop charger
CPU programmer
Speaker-microphone
Four-bay drop in charger
NiCd battery pack. 10.8 V, 800 mAh
Flexible antenna
VOX headset
|
|
