| GENERAL |
| Type: | Military VHF transceiver |
| Frequency range: | TX: 36-76 MHz
RX: 36-76 MHz |
| Tuning steps: | 25 KHz |
| Frequency stability: | Max ? ppm |
| Mode: | FM |
| Channels / memory management: | |
| Duplex shift / offset: | |
| Power supply: | 12 VDC |
| Current drain / power consumption: | RX: 120 mA
TX: 1.4 A (TRA-967/3) or 600 mA (TRA-967/1) |
| Antenna impedance / connector: | - / Threads for 1.2 m whip
50 ohm / BNC |
| Dimensions (W*H*D): | 166*76*285 mm (6.54*3*11.22"), with battery |
| Weight: | 3.5 Kg (7.72 lb), complete |
| Other features: |
150 Hz subtone. "Whisper mode" increases the mike gain by 20 dB.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 10.7 MHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 50 mW at ?% distortion / 50 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
RF output power
depending on version: | TRA-967/1: 1 W
TRA-967/3: 3 W |
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | England, 197x-198x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
CA4001
MA872
MA968A
MA968B
MA972
MA978
MA985B
MA986
MA988
MA989E
MA4009
TA970
|
VHF test set
Antenna matching unit
NiCd battery pack
Battery case (Ten LR14 / C batteries)
Antenna matching unit
Battery charger
Local control box
Remote control box
External PSU and speaker
Mounting frame
Rebroadcast control unit
Power amplifier, 25 W
|
|
