| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.405 MHz |
| Channels / tuning steps: | 40 |
| Mode: | AM |
| Frequency control: | PLL |
| Frequency stability: | ±300 Hz (No temperature reference) |
| Clarifier or Delta tune: | No |
| Power supply: | 13.2 VDC (Fixed power cord) |
| Current drain / power consumption: | RX: 500-800 mA
TX: Less than 1.7 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 115*35*180 mm (4.52*1.37*7.1") |
| Weight: | 800 g (1.76 lb) |
| Other features: | ANL. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.965 MHz
2nd IF: 450 KHz
|
| Sensitivity: | 0.5 uV (20 dB SINAD) |
| Squelch sensitivity: | 0.2 uV (Threshold)
1 mV (Tight) |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 5 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 4 W |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -54 dBm |
| Microphone impedance / connector: | ? ohm / 4-pin (Male locking ring jack) |
| Microphone input level: | 10 mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2003-200x (Discontinued) |
| Main PCB: |
PA-402AA by Uniden
|
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (1.2 MB, Multilanguage)
|
| Known markets and approvals: |
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
