| GENERAL |
| Type: | Citizen band transceiver, multinorm |
| Frequency range: |
| EC: | 26.965-27.405 MHz |
| EU: | 26.965-27.405 MHz |
| d: | 26.565-27.405 MHz |
| PL: | 26.960-27.400 MHz |
| U: | 26.965-27.405 / 27.60125-27.99125 MHz |
| In: | 26.965-27.275 MHz |
|
| Channels / tuning steps: | 27, 40 or 80 (Depending on setting) |
| Mode: | AM / FM (Depending on setting) |
| Frequency control: | PLL |
| Frequency stability: | ±300 Hz (No temperature reference) |
| Clarifier or Delta tune: | No |
| Power supply: | 13.2 VDC |
| Current drain / power consumption: | RX: 180-500 mA
TX: Less than 2 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 130*45*115 mm (5.12*1.77*4.53") |
| Weight: | 560 g (1.23 lb) |
| Other features: | ASC. VOX. Scanning. Two emergency channels. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.965 MHz
2nd IF: 450 KHz
|
| Sensitivity: |
AM: 0.5 uV (20 dB SINAD)
FM: 0.35 uV (20 dB SINAD)
|
| Squelch sensitivity: | 0.2 uV (Threshold)
1 mV (Tight) |
| Selectivity: | 60 dB (Adjacent channel) |
| Image rejection: | 60 dB |
| AF output power / speaker: | 3 W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 4 W |
| Modulation system: | |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -54 dBm |
| Microphone impedance / connector: | ? ohm / 6-pin (Male locking ring jack) |
| Microphone input level: | 3 mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 2024-202x |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price, february 2026 in Sweden: SEK 1095:-
|
| Related documents: |
User manual (3.3 MB, Multilanguage)
|
| Known markets and approvals: |
Europe
Directive 2014/53/EU and other applicable standards
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
ACFD601
ACFD602
ACMA113
|
Remote BT mike
Remote mike
DC/DC-converter (24 to 12 VDC, 3 A)
|
|
