| GENERAL |
| Type: | Amateur HF/VHF transceiver |
| Frequency range: |
TX: 10-160 m + WARC / 144-148 MHz
RX: 0.5-750 MHz
|
| Tuning steps: | 1 / 5 / 10 Hz, 10 / 100 KHz |
| Frequency stability: | ±? ppm |
| Mode: | TX: AM / FM / SSB / CW
RX: AM / FM / WFM / SSB / CW |
| Channels / memory management: |
35 regular
|
| Repeater shift / offset: | ? |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | RX: Less than 1.5 A
TX: Max 18 A |
| Antenna impedance / connector: | 50 ohm / Two SO-239 and two SMA jacks |
| Dimensions (W*H*D): | 340*177*157 mm (13.38*6.97*6.18") |
| Weight: | 3.6 Kg (7.94 lb) |
| Other features: |
7" color touch screen. Spectrum and waterfall display.
SD card slot. WiFi. Graphic SWR meter. SIM card slot.
CW decoder. HF antenna tuner. USB-C.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SDR
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| HF | 2 m |
|---|
| AM: | 25 W | 15 W |
| FM: | 100 W | 50 W |
| SSB (PEP): | 100 W | 50 W |
| CW: | 100 W | 50 W |
NB! The max output power may vary between bands
|
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By Shenzhen Zastone Technology Co. Ltd.), 2025-202x |
| Additional info: |
FCC ID: 2AJTBZT7500
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
