| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 400-470 MHz
RX: 87-108 / 136-174 / 400-480 MHz
|
| Tuning steps: | 2.5 / 5 / 6.25 / 10 / 12.5 / 25 / 50 KHz |
| Frequency stability: | ±2.5 ppm @ -10 to +60°C (14 to 140°F) |
| Mode: | TX: FM / NFM
RX: FM / NFM / WFM |
| Channels / memory management: |
128 regular
Non-volatile EEPROM storage
Scanning
|
| Repeater shift / offset: | Programmable |
| Power supply: | 13.8 VDC ±15% ("T" connector on pigtail) |
| Current drain / power consumption: | RX: 300 mA (Squelched)
TX: Max 5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 105*30*106 mm (4.13*1.18*4.17") |
| Weight: | 500 g (1.1 lb) |
| Other features: |
CTCSS/PL and DCS. DTMF. Twin RX. Three selectable backlite colors.
Scrambler. Detachable front panel. 1000/1450/1750/2100 Hz call tone.
PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: | 0.2 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2 W at 5% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2 m: | 25 W | 10 W | 5 W |
| 70 cm: | 25 W | 10 W | 5 W |
|
| Modulation system: | |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 8-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2018-202x (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (7.3 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
