| GENERAL |
| Type: | Amateur HF/VHF/UHF transceiver |
| Frequency range: |
TX: 28-29.7 / 50-54 / 136-174 / 420-470 MHz
RX: 28-29.7 / 50-54 / 108-136 / 136-174 / 420-470 MHz
|
| Tuning steps: | 2.5 / 5 / 6.25 / 7.5 / 8.33 / 10 / 12.5 / 15 / 25 / 30 / 50 / 100 kHz |
| Frequency stability: | ±? ppm |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM |
| Channels / memory management: |
800 regular
6 hyper memories
Non-volatile EEPROM storage
Scanning
|
| Repeater shift / offset: | Programmable |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | RX: 500 mA (Squelched)
TX: Max 8.5 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 140*41*168 mm (5.51*1.61*6.61") |
| Weight: | 1.2 Kg (2.65 lb) |
| Other features: |
CTCSS/PL and DCS. DTMF. 2-tone and 5-tone. Scrambler.
Crossband repeater. Dimmer. Detachable front panel.
PC programmable. Twin RX.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 49.95 MHz (Left RX) - 38.85 MHz (Right RX)
2nd IF: 450 KHz
|
| Sensitivity: | Ham bands: 0.2 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2 W at 5% distortion / 8 ohm |
| External speaker connector: | TS "Miniijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid 1 | Mid 2 | Low 1 |
|---|
| 10 m: | 50 W | 20 W | 10 W | 5 W |
| 6 m: | 50 W | 20 W | 10 W | 5 W |
| 2 m: | 50 W | 20 W | 10 W | 5 W |
| 70 cm: | 40 W | 20 W | 10 W | 5 W |
|
| Modulation system: | |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2015-20xx (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
