| GENERAL |
| Type: | 16/32-bit home computer |
| CPU: | Motorola MC68000 @ 7.09 MHz (PAL), 7.16 MHz (NTSC) |
| Operating system(s): | AmigaOS 2.05 and Workbench 2.05 |
| Memory: | ROM: 512 KB, Kickstart 2.05 (rev 37.299, 37.300 or 37.350)
RAM: 1 MB (Expandable to 2 MB and more) |
| Power supply: | 5 VDC, +12 VDC, -12 VDC (External PSU) |
| Current drain / power consumption: | ? W |
| Dimensions (W*H*D): | 350*75*240 mm (13.78*2.95*9.45") |
| Weight: | ? Kg (? lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated |
| Graphics: |
1280*200 pixels, 4 colors
1280*512i pixels, 4 colors
640*480 pixels, 4 colors (VGA)
640*200 pixels, 16 colors
640*512i pixels, 16 colors
320*200 pixels, 32 or 64 colors
320*512i pixels, 32 or 64 colors
Palette: 4096 colors
|
| Audio: |
Four hardware-mixed channels (Two left and two right)
8-bit PCM @ sampling frequency 28-56 KHz.
|
| Storage: |
Integrated 3.5" DD floppy, 880 KB
Optional internal ATA/IDE hard drive
|
| External I/O ports: |
| Analog RGB out: | ? |
| Video out: | ? (Composite) |
| RF out: | ? |
| Audio out: | ? (Stereo) |
| Game/mouse port: | Two ? |
| RS-232C port: | ? |
| Parallel: | ? (Centronics) |
| Floppy I/O: | ? |
| PCMCIA Type II slot: | ? (16-bit) |
| Memory expansion slot: | ? |
|
| Other: | Mouse.
Code name "June Bug". |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1992-1992 (Discontinued) |
| Additional info: |
Kickstart 2.05 rev. 37.299 did not have support for the internal ATA controller or
the PCMCIA interface. Rev. 37.300 had bugs that limited hard drive size to 40 MB.
Rev. 37.350 supported hard drives up to 4 GB.
Custom chips:
Fat Agnus - ECS display controller (aka Super Agnus)
Gayle - System address decoder and IDE controller
Paula - Audio and I/O controller
Super Denise - ECS display encoder
|
