Zetagi HP-201

A picture of Zetagi HP-201

SPECIFICATIONS

Type:SWR / Power meter
Frequency range: 26-30 MHz (Power and SWR)
3-200 MHz (SWR only)
Power measure ranges:2.5 W
25 W
250 W
2 KW
Insertion loss:Less than 0.1 dB
Impedance / connectors:52 ohm / Two SO-239
Power supply:-
Current drain / power consumption:-
Dimensions (W*H*D):140*80*130 mm (5.51*3.15*5.12")
Weight:730 g (1.61 lb)
Manufactured:Italy, 20xx-20xx
Other: SWR accuracy: 5%
Power accuracy: 10%

New price, april 2023 in Sweden: SEK 695:-
Related documents:User manual (158 KB, multi language)
Modifications and fixes:
Reviews:
Options / Accessories:
- -
