| GENERAL |
| Type: | Radar detector |
| Band(s): |
| X-band: | 10.525 GHz |
| K-band: | 24.150 GHz |
| Ka-band: | 33.4-36.0 GHz |
|
| Detector type(s): | |
| Antenna type: | Horn |
| RDD protection: | No |
| Laser detection: | No |
| Power supply: | 13.8 VDC |
| Current drain / power consumption: | ? mA |
| Dimensions (W*H*D): | 57*18*100 mm (2.25*0.69*3.94") |
| Weight: | ? g (? oz) |
| Other features: |
FAST (False Alert Suppression Technology).
City/Highway switch. Signal meter.
GaAs diode front-end.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? MHz
|
| Sensitivity: |
X-band: -114 dBm/cm2
K-band: -104 dBm/cm2
Ka-band: -100 dBm/cm2
|
| Selectivity: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1993-199x (Discontinued) |
| Additional info: |
New price 1993 in the US: $159.95
|
| Related documents: | |
| Reviews: | |
| Options / Accessories: |
|
