| GENERAL |
| Type: | Radar detector |
| Band(s): |
| X-band: | 10.525 GHz |
| K-band: | 24.150 GHz |
|
| Detector type(s): | |
| Antenna type: | Horn |
| RDD protection: | No |
| Laser detection: | No |
| Power supply: | 12 VDC |
| Current drain / power consumption: | ? mA |
| Dimensions (W*H*D): |
Detector unit: 89*44*95 mm (3.5*1.75*3.75")
Remote panel: 85*28*59 mm (3.34*1.09*2.34")
|
| Weight: |
Detector unit: ? g (? lb)
Remote panel: ? g (? oz)
|
| Other features: | Remote mount. High/Low sensitivity selectable. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? MHz
|
| Sensitivity: |
X-band: -110 dBm/cm2
K-band: -102 dBm/cm2
|
| Selectivity: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1987-198x (Discontinued) |
| Additional info: |
New price 1987 in the US: $179.95
New price 1988 in the US: $179.95
New price 1989 in the US: $179.95
|
| Related documents: | |
| Reviews: | |
| Options / Accessories: |
|
