| GENERAL |
| Type: | Professional land mobile transceiver |
| Frequency range: |
146-174 MHz (Any 1 MHz segment according to alignment)
|
| Tuning steps: | Channelized |
| Frequency stability: | ±?% |
| Mode: | FM |
| Channels / memory management: |
6 regular
Two XTALs per channel
|
| Repeater shift / offset: | Depending on XTALs |
| Power supply: | 9.6 VDC ±10% (NiCd pack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 62*151*43 mm (2.44*5.94*1.69") |
| Weight: | 450 g (15.9 oz), with battery pack |
| Other features: | Charger jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.5 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 65 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 1 W |
| Modulation system: | Phase modulation |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: |
Flyer (1.3 MB, In swedish)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
BL-01
BL-1002
BL-1002/10
BV-166
MO-166
NCB-166
|
Battery charger
Battery charger
Battery charger
Carrying case
Speaker-microphone
NiCd battery pack
|
|
