| GENERAL |
| Type: | Professional land mobile transceiver |
| Frequency range: |
146-174 MHz (Any 1 MHz segment according to alignment)
|
| Tuning steps: | Channelized |
| Frequency stability: | ±?% |
| Mode: | FM |
| Channels / memory management: |
6 regular
Two XTALs per channel
|
| Repeater shift / offset: | Depending on XTALs |
| Power supply: | 12 VDC ±10% (Alkaline batteries or NiCd pack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 78*240*49 mm (3.07*9.45*1.93") |
| Weight: | 950 g (2.09 lb) |
| Other features: | 5-tone CCIR selcall option. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.4 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 75 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: 4 W
Low: 1 W
|
| Modulation system: | Phase modulation |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 198x-198x (Discontinued) |
| Additional info: | |
| Related documents: |
Flyer (1.7 MB, In swedish)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
10x500 MAHS
BL-01
BL-1002
BL-1002/10
BLM-12
BVB-01
Colibri
MH-02
MHA-01
MOS-01
PA-25/2
TRA-04
VOX-01
ÖRF-01
|
NiCd batterypack
Battery charger
Battery charger
Battery charger
Charging unit for MHA-01
Carrying case
5-tone CCIR selcall module
Headset with boom mike
Vehicle mount with power and speaker jacks
Speaker-microphone
Power amplifier
Carrying harness
VOX unit
Earphone
|
|
