| Type: | Amateur HF linear amplifier |
| Frequency range / band(s): | 1.9-30 MHz |
| Output power: | AM / FM: Max 160 W
SSB: Max 250 W (PEP) |
| Drive power: | 5 or 10 W (Switchable) |
| Power supply: | 13.8 VDC (Fixed power cord) |
| Current drain / power consumption: | ? A |
| Impedance / connectors: | 50 ohm / Two SO-239 |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Manufactured: | Japan, 198x-198x (Discontinued) |
| Other: | Four selectable output levels. RX preamplifier. |
| Related documents: | Two MRF454 finals |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
