| GENERAL |
| Type: | Amateur HF transceiver |
| Frequency range: | 20 / 30 / 40 m |
| Tuning steps: | 50 / 100 Hz |
| Frequency stability: | ? ppm |
| Mode: | CW |
| Channels / memory management: | No |
| Repeater shift / offset: | No |
| Power supply: | 8-12.5 VDC (Internal battery pack)
or 12 VDC external (Male barrel jack, center positive) |
| Current drain / power consumption: | RX: Less than 50 mA (No signal)
TX: Less than 800 mA |
| Antenna impedance / connector: | 50 ohm / BNC
? ohm / Two banana jacks |
| Dimensions (W*H*D): | 183*107*38 mm (7.2*4.2*1.5") |
| Weight: | 510 g (18 oz), without batteries |
| Other features: | Iambic memory keyer (5-40 wpm). DDS. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 4.915 MHz
|
| Sensitivity: | 0.2 uV (No S/N reference) |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | 300 Hz |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / Headphones only |
| External speaker connector: | TRS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
5 W @ 12 VDC
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -50 dBc |
| Microphone impedance / connector: | - |
| Microphone input level: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 2008-2009 (Discontinued) |
| Additional info: |
Kit.
New price 2008 in the US: $200.00
New price 2009 in the US: $200.00
|
| Related documents: |
User manual v1 (435 KB)
User manual rev B (910 KB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
