| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 240-260 / 350-390 / 400-520 MHz
RX: 65-174 / 240-260 / 350-390 / 400-520 MHz
|
| Tuning steps: | ? KHz |
| Frequency stability: | ±? ppm |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
256 regular
Scanning
Non-volatile EEPROM storage
|
| Repeater shift / offset: | Programmable |
| Power supply: | 7.4 VDC (Li-Ion battery pack) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / SMA male |
| Dimensions (W*H*D): | 50*110*30 mm (1.97*4.33*1.18") |
| Weight: | 205 g (7.23 oz), with battery |
| Other features: |
CTCSS/PL and DCS. USB-C charging. Wireless frequency copy.
SOS alarm button. Roger beep. NOAA weather alert. VOX.
1.4" color LCD. Voice prompt. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Low |
|---|
| 2 m: | 6 W | ? W |
| 70 cm: | 4 W | ? W |
| 250 MHz: | ? W | ? W |
| 370 MHz: | ? W | ? W |
|
| Modulation system: | |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2022-202x (Discontinued) |
| Additional info: |
Was available in black or lime green.
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
EP3701A
|
Li-Ion battery pack. 7.4 V
|
|
