| GENERAL |
| Type: | Military VHF transceiver |
| Frequency range: | 40-43 |
| Tuning steps: | Channelized |
| Frequency stability: | Max ? ppm |
| Mode: | FM |
| Channels / memory management: |
4 regular
|
| Duplex shift / offset: | |
| Power supply: | 1.5 and 90 VDC |
| Current drain / power consumption: | RX: 13 mA (Anode) and 460 mA (Heater)
TX: 40 mA (Anode) and 720 mA (Heater) |
| Antenna impedance / connector: | ? ohm / ? |
| Dimensions (W*H*D): | Transceiver: 200*250*90 mm (7.87*9.84*3.54")
Battery pack: 160*280*90 mm (6.3*11*3.54") |
| Weight: | Transceiver: 3.1 Kg (6.83 lb)
Battery pack: 2.2 Kg (4.85 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 250 mW |
| Modulation system: | |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Sweden (By SRA), 1950-195x (Discontinued) |
| Additional info: |
Tubes.
This was originally a british Wireless Set No 88A, manufactured
on license here in Sweden by SRA. All Ra 130 were eventually modified
for better stability as Ra 130B.
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
