| GENERAL |
| Type: | Military HF transmitter |
| Frequency range: | 0.3-0.6 / 3-7 MHz |
| Tuning steps: | Channelized |
| Frequency stability: | 0.05% @ -30 to +50°C (-22 to +122°F) |
| Mode: | AM / CW |
| Channels / memory management: |
4 VFO presets
Ch.1: 300-600 KHz
Ch.2: 3-4.8 MHz
Ch.3: 4-6.4 MHz
Ch.4: 4.37-7 MHz
|
| Power supply: | 20-28 VDC (Dynamotor supply) |
| Current drain / power consumption: | 16 A @ 25 VDC |
| Antenna impedance / connector: | ? ohm / ? |
| Dimensions (W*H*D): | 384*260*171 mm (15.12*10.25*6.75") |
| Weight: | 15.65 Kg (34.5 lb), with tubes and shockmount |
| Other features: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
~40 W
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1941-194x (Discontinued) |
| Additional info: |
Three 807 and four 12SK711 tubes.
Surplus price, late fourties in the US: $49.95
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
