| GENERAL |
| Type: | Military HF transceiver |
| Frequency range: | 2-7 MHz |
| Tuning steps: | Channelized |
| Frequency stability: | Max ? ppm |
| Mode: | AM / CW |
| Channels / memory management: |
45 regular with fine tuning
|
| Duplex shift / offset: | No |
| Power supply: | 10-16 VDC |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 100 ohm / Spring terminals (For balanced wire antenna)
50 ohm / Mini BNC |
| Dimensions (W*H*D): | 200*88*114 mm (7.87*3.46*4.49") |
| Weight: | 4.4 Kg (9.7 lb), with battery pack |
| Other features: | Fully waterproof. Integrated morse key. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 8 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.5 uV (No S/N reference) |
| Squelch sensitivity: | |
| Selectivity: |
AM: 6 KHz (No dB reference)
CW: 300 Hz (No dB reference)
|
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / No internal speaker |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 4 W |
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | UK (By Rank Precision Industries Ltd.), 1968-197x (Discontinued) |
| Additional info: |
Solid state, long range patrol radio. Mainly used by the SAS.
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
