| GENERAL |
| Type: | License-free PMR446 / SRBR dual band transceiver |
Frequency range
depending on region: |
PMR446: 446.00625-446.19375 MHz (Sweden/Norway/EU)
SRBR/KDR: 444.600-444.975 MHz (Sweden/Norway)
|
Channels / tuning steps
depending on region: |
Sweden: 24 (16 PMR446 + 8 SRBR)
Norway: 22 (16 PMR446 + 6 SRBR)
EU: 16 PMR446, no SRBR
|
| Frequency stability: | ±2.5 ppm @ -20 to +55°C (-4 to +131°F) |
| Mode: |
PMR446: NFM
SRBR/KDR: FM
|
| Memory channels / management: | - |
| Repeater shift / offset: | Simplex only |
| Power supply: | 3.7 VDC (Li-Ion battery) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | 42*75*17 mm (1.65*2.95*0.67") |
| Weight: | 66 g (2.32 oz) |
| Other features: |
CTCSS/PL and DCS. Scanning. Micro-USB charging jack.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 500 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
High: Max 500 mW (ERP)
Low: ? mW (ERP
|
| Modulation system: | |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2024-202x |
| Additional info: |
New price, july 2026 in Sweden: SEK 1495:-/pair
|
| Related documents: |
User manual (1.7 MB, in Swedish and norwegian)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
47340
47341
47342
47751
49185
|
Battery. 3.7 V, 1100 mAh
Desk charger
4-bay multicharger
Headset "Secret service"
Headset
|
|
