| GENERAL |
| Type: | License-free LPD transceiver |
| Frequency range: |
Standard
433.075-434.775 MHz
Export mode
420-470 MHz
|
| Channels / tuning steps: | 69 |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Memory channels / management: | 9 regular |
| Repeater shift / offset: | Simplex only |
| Power supply: | 4.8-6 VDC (Four R03 / AAA alkaline or rechargeable batteries) |
| Current drain / power consumption: | RX: 30-50 mA
TX: Max 90 mA @ 10 mW output power |
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | 50*83*28 mm (1.97*3.27*1.1") |
| Weight: | 98 g (3.46 oz) |
| Other features: | CTCSS/PL. VOX. Dual watch. Scanning. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 21.4 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.4 uV (20 dB S+N+D)/N |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 300 mW at 10% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Standard
10 mW (ERP)
Export mode
600 mW
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | xxxx-200x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
