| GENERAL |
| Type: | License-free FRS transceiver |
| Frequency range: | 462.5625-467.7125 MHz |
| Channels / tuning steps: | 14 |
| Frequency stability: | ? ppm |
| Mode: | NFM |
| Memory channels / management: | - |
| Repeater shift / offset: | Simplex only |
| Power supply: | 4.8-6 VDC (Four R6 / AA alkaline or NiCd batteries) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | 55*122*38 mm (2.16*4.8*1.5") |
| Weight: | 145 g (5.11 oz) |
| Other features: |
CTCSS/PL "Quiet codes". Dual watch. Scanning. 3 memories.
Water and shock resistant. Charger jack.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | 0.5 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 45 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 250 mW at 5% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 500 mW (ERP) |
| Modulation system: | |
| Max FM deviation (Factory set): | ±2.5 KHz |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (By Tekcom Industries Ltd.), 2001-200x (Discontinued) |
| Additional info: |
FCC ID: AAO2101860
New price 2002 in the US: $99.99
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
