| GENERAL |
| Type: | License-free FRS transceiver |
| Frequency range: |
FRS: 462.5625-467.7125 MHz
WX: 162.400-161.650 MHz (RX only)
|
| Channels / tuning steps: |
14 FRS
8 NOAA weather channels
Scanning
|
| Frequency stability: | ? ppm |
| Mode: | NFM |
| Memory channels / management: | - |
| Repeater shift / offset: | Simplex only |
| Power supply: | 3.6-4.5 VDC (Three R6 / alkaline batteries or NiMH pack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | 56*97*32 mm (2.19*3.81*1.25") |
| Weight: | ? g (? oz) |
| Other features: |
CTCSS/PL "Quiet codes". VOX. Vibracall. Scrambler.
Weather alert. Call tone.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 500 mW (ERP) |
| Modulation system: | |
| Max FM deviation (Factory set): | ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Malaysia, 2001-200x (Discontinued) |
| Additional info: |
FCC ID: AZ489FT4841
New price 2002 in the US: $99.99
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
