| GENERAL |
| Type: | License-free FRS transceiver |
| Frequency range: | 462.5625-467.7125 MHz |
| Channels / tuning steps: | 14 |
| Frequency stability: | 2.5 ppm @ -20 to +50°C (-4 to +122°F) |
| Mode: | NFM |
| Memory channels / management: | - |
| Repeater shift / offset: | Simplex only |
| Power supply: | 4.8-6 VDC (Four R6 / AA alkaline or rechargeable batteries)
or 9 VDC external (Male barrel jack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | 50 ohm / Non-removable antenna |
| Dimensions (W*H*D): | 50*200*35 mm (1.97*4.33*1.38"), including the antenna |
| Weight: | 132 g (4.66 oz), without batteries |
| Other features: | CTCSS/PL "Quiet codes". Call tone. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | 0.5 uV (12 dB SINAD) |
| Squelch sensitivity: | |
| Selectivity: | 45 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 250 mW at 5% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | Less than 500 mW (ERP) |
| Modulation system: | |
| Max FM deviation (Factory set): | ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / TRS "Subminijack" (2.5 mm) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China (Hong Kong), 1999-200x (Discontinued) |
| Additional info: |
FCC ID: AAO21-1811
New price 2000 in the US: $99.99
New price 2001 in the US: $99.99
|
| Related documents: |
User manual (143 KB)
PLL: MB1511
RF driver: 2SC3356
RF final: BLT50
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
21-591
21-592
|
Camo case
Black leather case
|
|
