| GENERAL |
| Type: | License-free FRS transceiver |
| Frequency range: | 462.5625-467.7125 MHz |
| Channels / tuning steps: | 14 |
| Frequency stability: | ? ppm |
| Mode: | NFM |
| Memory channels / management: | - |
| Repeater shift / offset: | Simplex only |
| Power supply: |
3.6-4.5 VDC (Three R6 / AA alkaline or rechargeable batteries)
or 5.5 VDC external
|
| Current drain / power consumption: | RX: Max 33-? mA
TX: Max 260 mA @ 4.5 VDC |
| Antenna impedance / connector: | Non-removable foldable antenna |
| Dimensions (W*H*D): | 55*102*28 mm (2.16*4*1.1") |
| Weight: | 184 g (6.5 oz), with batteries |
| Other features: | CTCSS/PL. Scanning. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 23.05 MHz
2nd IF: 450 KHz
|
| Sensitivity: | 0.18 uV (12 dB SINAD) |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 100 mW at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 300 mW |
| Modulation system: | Variable reactance |
| Max FM deviation (Factory set): | ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ? |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1997-199x (Discontinued) |
| Additional info: | |
| Related documents: | User manual and schematic diagram (483 KB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
EBC-6
EDC-78
EDH-18
EME-4
EME-12
EME-13
EME-15
EMS-9Z
ESC-27
|
Mobile bracket
Wall charger
Car lighter DC cable with 5.5 VDC converter
Earphone-microphone
Headset with VOX. Earpad type
Headset with VOX. Earphone type
Tie-pin mic and earphone with VOX
Speaker-microphone
Soft case
|
|
