| GENERAL |
| Type: | VHF/UHF receiver/scanner |
| Frequency range: | 68-88 / 144-174 / 410-512 MHz |
| Tuning steps: | VHF: 5 KHz
UHF: 12.5 KHz |
| Frequency stability: | ? ppm |
| Mode: | FM |
| Channels / memory management: |
8 regular @ 10 channels per second
RAM storage with 9 V battery backup
|
| Power supply: | Mains: 220 VAC (Fixed power cord)
or 12-15 VDC (2-pin connector) |
| Current drain / power consumption: | Less than 10 W @ 220 VAC |
| Antenna impedance / connector: | 50 ohm / DIN41585 (Motorola) or built-in telescopic whip |
| Dimensions (W*H*D): | 260*80*270 mm (10.2*3.2*10.6") |
| Weight: | 2.4 Kg (5.3 lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz
|
| Sensitivity: | VHF: 1 uV
UHF: 2 uV (20 dB S/N) |
| Selectivity: | 18 KHz (-6 dB)
34 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 2 W at ?% distortion / ? ohm |
| External speaker connector: | 6.3 mm (1/4"), 4-8 ohm |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1980-198x (Discontinued) |
| Additional info: | New price 1983 in Sweden: SEK 1465:- |
| Related documents: |
User manual (2 MB, in swedish & english)
FM-IF: MC3357P
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
