| GENERAL |
| Type: | HF receiver |
| Frequency range: |
0.54-38.1 MHz in five bands
1: 0.54-1.23 MHz
2: 1.18-2.85 MHz
3: 2.75-6.82 MHz
4: 6.75-16.4 MHz
5: 15.4-38.1 MHz
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ? ppm |
| Mode: | AM / CW |
| Channels / memory management: |
None
|
| Power supply: | Mains: 110 VAC |
| Current drain / power consumption: | ? W |
| Antenna impedance / connector: | ? ohm / ? |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne
IF: 465 KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1936-1937 (Discontinued) |
| Additional info: |
11 tubes
New price 1936 in the US: $100.00
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
