| GENERAL |
| Type: | Citizen band transceiver, multinorm |
Frequency range
depending on setting: |
| EC: | 26.965-27.405 MHz |
| EU: | 26.965-27.405 MHz |
| IN: | 26.965-27.275 MHz |
| D: | 26.565-27.405 MHz |
| U: | 27.60125-27.99125 / 26.965-27.405 MHz |
| PL: | 26.960-27.400 MHz |
| RU: | 25.615-30.105 MHz (After modification)
|
|
| Channels / tuning steps: | 27, 40, 80 or 400 + alphas |
| Mode: | AM / FM |
| Frequency control: | PLL |
| Frequency stability: | ?% |
| Clarifier or Delta tune: | No |
| Power supply: | 10.8-15.6 VDC (Male 3-pin jack) |
| Current drain / power consumption: | RX: 180-500 mA
TX: Less than 2 A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 170*52*160 mm (6.69*2.05*5.3") |
| Weight: | 1.1 Kg (2.42 lb) |
| Other features: |
PA. ANL/NB. ASC. VOX. Tone hi-cut. Talkback. Dimmer.
Two programmable emergency channels. Roger beep.
USB charging port (5 V, 2.1 A). Seven selectable backlite
colors.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: ? MHz
2nd IF: 455 KHz - Ceramic filter: LT455HT |
| Sensitivity: |
AM: 0.5 uV (20 dB SINAD)
FM: 0.35 uV (20 dB SINAD)
|
| Squelch sensitivity: | 0.2 uV (Threshold)
1 mV (Tight) |
| Selectivity: | 10 KHz (-60 dB) |
| Image rejection: | 60 dB |
| AF output power / speaker: | ? W at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 8 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
Standard
AM: 4 W
FM: 4 W
Modified
AM: 8 W
FM: 20 W
|
| Modulation system: | |
| Max AM modulation (Factory set): | ?% |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -54 dB |
| Microphone impedance / connector: | ? ohm / 6-pin (Male GX16 locking ring jack) |
| Microphone input level: | 3 mV (No reference) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2018-202x |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: |
New price, december 2018 in Germany: €209.00
|
| Related documents: |
User manual (2.4 MB, multilanguage)
|
| Known markets and approvals: |
Europe
Directive 2014/53/EU compliant
|
| Sams Photofact #: | None |
| Modifications and fixes: |
Frequency expansion and power mods (431 KB)
|
| Reviews: | |
| Options / Accessories: |
|
