| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 26.965-27.255 MHz |
| Channels / tuning steps: | 1-23 + 11A |
| Mode: | AM / FM |
| Frequency control: | PLL |
| Frequency stability: | ±?% |
| Clarifier or Delta tune: | No |
| Power supply: | 9-12 VDC (Eight LR6 / AA batteries) |
| Current drain / power consumption: | RX: 35 mA (Standby)
TX: 430-570 mA |
| Antenna impedance / connector: | 50 ohm / TNC |
| Dimensions (W*H*D): | 68*190*42 mm (2.7*7.5*1.65") |
| Weight: | 450 g (15.9 oz), without batteries |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | Hi: 2 W
Lo: 1 W |
| Modulation system: | |
| Max AM modulation (Factory set): | ? % |
| Max FM deviation (Factory set): | ±? KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1987-198x (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: |
User manual (2.4 MB, Swedish)
|
| Known markets and approvals: |
Sweden
Televerket: RL 2024/87
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
