| GENERAL |
| Type: | Citizen band transceiver |
| Frequency range: | 27.005-27.135 MHz |
| Channels / tuning steps: | 12 (Channel 4 to 15) |
| Mode: | AM |
| Frequency control: | PLL |
| Frequency stability: | ±0.002% @ -10 to +55°C (14 to 131°F) |
| Clarifier or Delta tune: | No |
| Power supply: | 12 VDC (Alkaline batteries or NiCd pack) |
| Current drain / power consumption: | RX: ? mA
TX: ? mA |
| Antenna impedance / connector: | - / Fixed telescopic whip |
| Dimensions (W*H*D): | 80*215*55 mm (3.15*8.46*2.16") |
| Weight: | ? g (? lb) |
| Other features: | S-/battery meter. Tonecall. Charging jack. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.695 MHz
2nd IF: 455 KHz
|
| Sensitivity: | 0.3 uV (10 dB S/N) |
| Squelch sensitivity: | 0.3 uV (Threshold)
80 uV (Tight) |
| Selectivity: | 75 dB (Adjacent channel) |
| Image rejection: | 70 dB |
| AF output power / speaker: | 600 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: | 500 mW |
| Modulation system: | |
| Max AM modulation (Factory set): | 98% |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / Internal only |
| Microphone input level: | - |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1978-1979 (Discontinued) |
| Main PCB: | |
| Sub PCBs: | |
| Additional info: | |
| Related documents: | |
| Known markets and approvals: |
West Germany
FTZ-Nr. PR27-444P/78
|
| Sams Photofact #: | None |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
