| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 240-260 / 400-480 MHz
RX: 87-108 / 136-174 / 240-260 / 400-480 MHz
|
| Tuning steps: | 5 / 6.25 / 10 / 12.5 / 15 / 25 KHz |
| Frequency stability: | ±2.5 ppm @ -20 to +60°C (-4 to +140°F) |
| Mode: | TX: FM / NFM
NX: FM / NFM / WFM |
| Channels / memory management: |
200 regular
Non-volatile EEPROM storage
Scanning
|
| Repeater shift / offset: | Programmable |
| Power supply: | 13.8 VDC ±15% ("T" connector on pigtail) |
| Current drain / power consumption: | RX: ? mA
TX: Max ? A |
| Antenna impedance / connector: | 50 ohm / SO-239 |
| Dimensions (W*H*D): | 98*35*118 mm (3.86*1.38*4.64") |
| Weight: | 408 g (14.4 oz) |
| Other features: |
CTCSS/PL and DCS. DTMF. 2-tone and 5-tone. PC programmable.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SoC / Homodyne (Direct conversion)
|
| Sensitivity: |
FM: 0.25 uV (No SINAD reference)
NFM: 0.35 uV (No SINAD reference)
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | More than 60 dB (Adjacent channel) |
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Low |
|---|
| 2 m: | 25 W | ? W |
| 250 MHz: | 25 W | ? W |
| 70 cm: | 20 W | ? W |
|
| Modulation system: | |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / 8-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 201x-202x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
