| GENERAL |
| Type: | Amateur VHF/UHF transceiver |
| Frequency range: |
TX: 136-174 / 400-480 MHz
RX: 0.153-0.279 / 0.5-1.8 / 2.3-30 / 64-108 / 108-174 / 400-480 MHz
NB! RX/TX 200-260 MHz was also optional on early production runs
|
| Tuning steps: | 2.5 / 5 / 6.25 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 KHz |
| Frequency stability: | ±2.5 ppm @ -10 to +60°C (14 to 140°F) |
| Mode: | TX: FM / NFM
RX: AM / FM / NFM / WFM |
| Channels / memory management: |
512 regular
Non-volatile EEPROM storage
|
| Repeater shift / offset: | Programmable |
| Power supply: | 12-14 VDC |
| Current drain / power consumption: | RX: Less than 500 mA (Squelched)
TX: Less than 11 A |
| Antenna impedance / connector: | TX/RX: 50 ohm / SO-239
RX only: 50 ohm / BNC |
| Dimensions (W*H*D): | Main unit: 153*45*150 mm (6.02*1.77*5.9")
Front panel: 150*57*33 mm (5.9*2.24*1.3") |
| Weight: | 1.6 Kg (3.53 lb) |
| Other features: |
CTCSS/PL and DCS with tone scan. 2-tone and 5-tone. DTMF. Detachable
front panel. Crossband repeater. DTMF microphone. Packet jack. WX alert.
Selectable backlite colors. PC programmable. Diversity reception.
Twin RX (V/V, V/U, U/U).
Built-in very low power WFM transmitter so the received audio can be heard
in your car stereo, domestic HiFi equipment and similar.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
?
|
| Sensitivity: |
Ham bands: 0.2 uV (12 dB SINAD)
|
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: |
FM
12 KHz (-6 dB)
30 KHz (-60 dB)
NFM
10 KHz (-6 dB)
24 KHz (-60 dB)
|
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm), 4-16 ohm |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2 m: | 50 W | 25 W | 5 W |
| 70 cm: | 40 W | 25 W | 5 W |
|
| Modulation system: | Variable reactance |
| Max AM modulation (Factory set): | No AM |
| Max FM deviation (Factory set): | FM: ±5 KHz
NFM: ±2.5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | 2 Kohm / 8-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2018-202x |
| Additional info: |
Specifications and functions may vary slightly depending on production run.
|
| Related documents: |
Quick reference (1.4 MB)
|
| Modifications and fixes: | |
| Reviews: | Practical Wireless: July 2026, page 12 |
| Options / Accessories: |
?
?
?
?
|
Bluetooth microphone
Barometer/altimeter/thermometer unit
GPS unit
Bluetooth unit
|
|
