| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
Europe
TX: 144-146 MHz
RX: 137-174 MHz
USA
TX: 144-148 MHz
RX: 137-174 MHz
|
| Tuning steps: | 5 / 10 / 12.5 / 15 / 20 / 25 / 50 / 100 KHz |
| Frequency stability: | ±5 ppm @ -10° to +60°C (14° to 140°F) |
| Mode: | FM |
| Channels / memory management: |
200 regular
1 home
10 PMS/scan edge pairs
10 NOAA weather channels
|
| Repeater shift / offset: | ±600 KHz |
| Power supply: | 7.2 VDC (Battery pack)
or 6-16 VDC external |
| Current drain / power consumption: | RX: 20-125 mA
TX: Max 1.5 A |
| Antenna impedance / connector: | 50 ohm / SMA |
| Dimensions (W*H*D): | 60*120*32 mm (2.36*4.72*1.26") |
| Weight: | 390 g (13.8 oz), with FNB-83, antenna and belt clip |
| Other features: |
CTCSS/PL and DCS. Dual watch. DTMF. ARTS. 1750 Hz call tone.
Submersible.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 21.7 MHz
2nd IF: 450 KHz
|
| Sensitivity: | 140-150 MHz: 0.16 uV (12 dB SINAD) |
| Selectivity: | 12 KHz (-6 dB)
35 KHz (-60 dB) |
| Image rejection: | |
| AF output power / speaker: | 700 mW at 10% distortion / 16 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2 m: | 5 W | 2 W | 500 mW |
|
| Modulation system: | Variable reactance |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -60 dB @ Hi and Middle power |
| Microphone impedance / connector: | 2 Kohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 2005-200x (Discontinued) |
| Additional info: | |
| Related documents: | User manual (3.1 MB) |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
CMP-460A
CN-3
CT-91
E-DC-5B
E-DC-6
FBA-25A
FNB-83
FTD-7
MH-57A4B
NC-88B
NC-88C
NC-88U
VAC-370
VC-24
VC-27
YHA-68
|
Waterproof speaker-microphone
BNC-to-SMA adapter
Microphone adapter
DC cable with cigarette-lighter adapter
DC cable, plug and wire only
Dry battery case (6*LR6/AA batteries)
NiMH battery pack. 7.2 V, 1400 mAh
DTMF paging unit
Speaker-microphone
10-hour battery charger. 100-120 VAC
10-hour battery charger. 230-240 VAC
10-hour battery charger. 230 VAC
Desktop rapid charger
VOX headset
Earpiece-microphone
2 m antenna
|
|
