| GENERAL |
| Type: | Amateur HF transceiver |
| Frequency range: |
TX: 10-80 m + WARC
RX: 0.55-30 / 88-108 MHz
|
| Tuning steps: | ? KHz |
| Frequency stability: | ±1.5 ppm @ 25°C (77°F), within 30 minutes after power on |
| Mode: | TX: AM / SSB / CW
RX: AM / SSB / CW / WFM |
| Channels / memory management: |
|
| Repeater shift / offset: | No |
| Power supply: | 9-15 VDC (Barrel connector, center positive) |
| Current drain / power consumption: | RX: 370 mA
TX: Max 2.8 A |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 120*40*135 mm (4.72*1.58*5.32") |
| Weight: | 720 g (1.59 lb) |
| Other features: | Electronic keyer. Spectrum scope. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
SDR architecture
16 bit sampling
|
| Sensitivity: |
AM: 10 uV (10 dB S/N)
SSB: 0.5 uV (10 dB S/N)
CW: 0.25 uV (10 dB S/N)
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 300 mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| Pwr |
|---|
| AM: | 5 W |
| SSB (PEP): | 5 W |
| CW: | 5 W |
Nominal output power @ 13.8 VDC
|
| Modulation system: | |
| Max FM deviation (Factory set): | No FM |
| Spurious emissions: | Better than -50 dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Modular) |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | China, 2022-202x |
| Additional info: |
New price, october 2022 in England: £329.99
New price, october 2022 in Germany: 399.99 Euro
|
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
DE-19
GNR-1
GY-03
L4001
VG4
XPA125B
|
Digital adapter. For digital modes like FT-8 and similar
External digital audio noise filter
External speaker
Accessory control cable
Vertical base antenna. 10/15/20/40 m
Linear amplifier. 100 W
|
|
