Sinclair QL (Quantum Leap)

SPECIFICATIONS
Type:8/16/32-bit home and business computer
CPU:Motorola MC68008 @ 7.5 MHz
Operating system:Superbasic and QDOS (A multitasking operative)
Memory:ROM: 48 KB (Expandable to 64 KB)
RAM: 128 KB (Expandable to 640 KB)
Sound:Beeper
Graphics:256*256 pixels, 8 colors
512*256 pixels, 4 colors
85*25, 64*25 and 40*25 text
Storage:2 built-in 100 KB ZX Microdrives
Optional floppy
Input:Integrated keyboard
I/O ports:Cartridge slot
2*RS232C
2*QLAN ports
2*joystick
External ZX Microdrive bus
RGB monitor out
TV out
Voltage:External PSU
Power consumption:
Dimensions (W*H*D):? mm (?")
Weight:? Kg (? lbs)
Manufactured:1984-1986 (Discontinued)
Other:
Related documents:
Modifications:
Notable "ham" software:
