| GENERAL |
| Type: | 8-bit trainer computer |
| CPU: | MOS 6502 @ 1 MHz |
| Operating system(s): | TIM (Terminal Interface Monitor) |
| Memory: | ROM: 1152 Bytes
RAM: 2 KB |
| Power supply: | ? V |
| Current drain / power consumption: | ? mA |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? g (? oz) |
|
|
|
|
| I/O |
| Keyboard: | Integrated 23-key keypad |
| Graphics: | Six 7 segment LEDs |
| Audio: | No |
| Storage: | Tape recorder |
| External I/O ports: |
| Serial ports: | Two ? (Not RS-232C compliant!) |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1975-1976 (Discontinued) |
| Additional info: |
MOS technology was bought by Commodore in 1976, and
the KIM-1 was then marketed under that brand name.
|
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
|
