| GENERAL |
| Type: | 8-bit home computer |
| CPU: | Zilog Z80 @ 3.58 MHz |
| Operating system(s): | MSX Basic |
| Memory: | ROM: 32 KB
RAM: 64 KB |
| Power supply: | Mains |
| Current drain / power consumption: | Max 20 W @ 240 VAC |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated |
| Graphics: |
TMS9929NL with 16 KB VRAM
Text: 40*24 or 32*24 characters
256*192 pixels, 16 colors
|
| Audio: | 3 channels, 8 octaves |
| Storage: |
Tape recorder
Optional disk drive
|
| External I/O ports: |
| Game ports: | Two ? |
| Video out: | ? |
| RF out: | ? |
| Cartridge port: | ? |
| Tape I/O: | ? |
| Expansion port: | ? |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | South Korea, 1984-198x (Discontinued) |
| Additional info: | |
| Related documents: |
Sound generator: AY-3-8910
|
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
|
