| GENERAL |
| Type: | 8-bit home computer |
| CPU: | Zilog Z80A @ 1.77 MHz |
| Operating system(s): | Microsoft Basic Level II
Optional TRS-DOS or NEWDOS 80 (For disk drive systems) |
| Memory: | ROM: 12 KB
RAM: 16 KB (Expandable to 48 KB) |
| Power supply: | Mains |
| Current drain / power consumption: | ? W |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated |
| Graphics: |
Text: 32*16 or 64*16 characters
128*48 pixels, monochrome
Higher resolution option
|
| Audio: | Optional sound generator |
| Storage: |
Tape recorder
Optional disk drives
|
| External I/O ports: |
| Video out: | ? |
| RF out: | ? |
| Tape I/O: | ? |
| Expansion bus: | 50-pin ? |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Hong Kong, 1981-198x (Discontinued) |
| Additional info: |
TRS-80 Model 1 compatible.
New price 1982 in Sweden: SEK 4460:-
|
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | Radio & Television (Sweden): September 1981 (#9) |
| Some options / Accessories: |
EG-3014
EG-3016
EG-3020
EG-3021
EG-3022
EG-3050
EG-3085
|
Expander with Centronics, floppy I/F + extra RAM sockets and edge connector
Centronics/Parallel interface
RS-232C I/F (EG-3014 required)
Double density kit
S-100 bus I/F (EG-3014 required)
Printer
Printer
|
|
