| GENERAL |
| Type: | 8-bit home computer |
| CPU: | Rockwell R6512A @ 2 MHz |
| Operating system(s): | Acorn MOS |
| Memory: | ROM: 48 KB
RAM: 64 KB |
| Power supply: | |
| Current drain / power consumption: | |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
|
|
|
|
| I/O |
| Keyboard: | Integrated |
| Graphics: |
Motorola 6845 CRT controller and Mullard SAA5050 teletext chip
Text:
Mode 3: 80*25 characters, 2 colors
Mode 6: 40*25 characters, 2 colors
Mode 7: 40*25 characters (Teletext), 8 colors
Graphics
Mode 0: 640*256 pixels, 2 colors
Mode 1: 320*256 pixels, 4 colors
Mode 2: 160*256 pixels, 8 colors
Mode 4: 320*256 pixels, 2 colors
Mode 5: 160*256 pixels, 4 colors
|
| Audio: |
SN76489 chip
4 channels (1 noise, 3 melodic)
Optional speech synthesis with the TMS5220 and TMS6100 chips
|
| Storage: |
Tape recorder (300/1200 bd)
Optional floppy and hard drives
|
| External I/O ports: |
| RGB out: | ? |
| Video out: | ? (Composite) |
| RF out: | ? (PAL only) |
| Tape I/O: | ? |
| RS-423 port: | ? |
| Parallel port: | ? (Centronics) |
| User port: | 20-pin |
| Analog I/O port: | ? |
| 1 MHz expansion port: | ? |
| External 2nd CPU connector: | ?-pin ("The Tube") |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 1985-19xx (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
|
?
|
Econet network interface (100 KBit/s)
|
|
