| GENERAL |
| Type: | 8/16-bit semi-professional computer |
| CPU: | Motorola MC68000 @ 8/16 MHz |
| Operating system(s): | TOS and GEM |
| Memory: | ROM: 256 KB
RAM: 1, 2 or 4 MB depending on version (Expandable to 8 MB) |
| Power supply: | Mains |
| Current drain / power consumption: | |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
|
|
|
|
| I/O |
| Keyboard: | External |
| Graphics: |
320*200 pixels, 16 colors
640*200 pixels, 4 colors
640*400 pixels, monochrome
Text: 40*25 and 80*25
"Blitter" graphics co-processor
|
| Audio: |
Yamaha YM2149
3 channels, 8 octaves in stereo
|
| Storage: |
Internal 720 KB (early) 1.44 MB (later) floppy (MS-DOS compatible)
SCSI hard drive
Optional extra floppy
|
| External I/O ports: |
| Keyboard: | ? |
| RGB out: | ? |
| RF out: | ? |
| Parallel: | ? (Centronics) |
| Joysticks: | Two ? |
| MIDI I/O: | ? |
| Audio out: | ? |
| Floppy I/O: | ? |
| Cartridge slot: | ? |
| VME bus: | ? |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Designed in the USA, 1991-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Notable "ham" software: | ST-Wefax (With a Kantronics KPC or KAM) - By GM4JJJ (SK) |
| Reviews: | |
| Some options / Accessories: |
|
