GENERAL |
Type: | ?-bit home computer |
CPU: | 6502B @ 1.77 MHz (PAL), 1.78 MHz (NTSC) |
Operating system(s): | Atari Basic / Atari 8-bit OS |
Memory: | ROM: 10 KB RAM: 16 KB (Some early versions were shipped with only 8 KB) |
Power supply: | 9 VAC (Male barrel jack) |
Current drain / power consumption: | |
Dimensions (W*H*D): | ? mm (?") |
Weight: | ? Kg (? lb) |
|
|
|
|
I/O |
Keyboard: | Integrated membrane type |
Graphics: |
320*192 pixels, monochrome
160*96 pixels, 128 colors
4 sprites, raster interrupts
|
Audio: |
Atari "POKEY" (AMI C012294B-01)
4 oscillators and noise mixer or 2*AM digital
Built-in speaker
|
Storage: | Optional program recorder Optional floppy |
External I/O ports: |
Cartridge slot: |   30-pin edge connector |
Joystick: |   Four DE-9p / DB-9m |
RF out: |   Phono/RCA (On the main board) |
Serial I/O: |   13-pin (Peripheral jack) |
|
Other: | |
|
|
|
|
MISCELLANEOUS |
Manufactured: | Hong Kong (Designed in USA), 1979-1983 (Discontinued) |
Additional info: |
Codename "Candy".
FCC ID: BPA83A400.
|
Related documents: | |
Modifications and fixes: | |
Notable "ham" software: | |
Reviews: | |
Options / Accessories: |
410
|
Program recorder (Tape recorder)
|
|
