| GENERAL |
| Type: | 8-bit home computer |
| CPU: | MOS 6502 @ 1 MHz |
| Operating system(s): | "Wozmon" system monitor. (Apple BASIC option on tape) |
| Memory: | ROM: 256 Bytes
RAM: 4 KB (Expandable up to 64 KB) |
| Power supply: | 8-12 VAC and 26-28 VAC (Pin header) |
| Current drain / power consumption: | 3 A @9 VAC
1 A @ 27 VAC |
| Dimensions (W*H*D): | 394*229*? mm (15.5*9*?") |
| Weight: | ? g (? lb) |
|
|
|
|
| I/O |
| Keyboard: | External |
| Graphics: |
Signetics 2513 with 1 KB VRAM
280*192 pixels (Monochrome)
40*24 text
|
| Audio: | No |
| Storage: | Optional tape recorder interface (150 bd) |
| External I/O ports: |
| Keyboard: | 16-pin DIL socket |
| Expansion port: | 44-pin header and edge connector |
| Video out: | Pin header (Composite) |
|
| Other: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 1976-1976 (Discontinued) |
| Additional info: |
Around 200 was manufactured. This first attempt was
sold as a board only.
New price, october 1976 in the US: $666.66 (With 4 KB RAM)
|
| Related documents: |
User manual (2 MB)
|
| Modifications and fixes: | |
| Notable "ham" software: | |
| Reviews: | |
| Some options / Accessories: |
|
?
|
Apple I cassette interface
|
|
