| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
TX: 50-54 / 144-148 MHz
RX: 50-54 / 136-174 MHz
|
| Tuning steps: | ? KHz |
| Frequency stability: | ±? ppm |
| Mode: | FM / SSB / CW |
| Channels / memory management: |
100 regular
|
| Repeater shift / offset: | Programmable |
| Power supply: | 12-14 VDC (2-pin connector) |
| Current drain / power consumption: | RX: 0.4 to 1.4 A
TX: Max 6 A |
| Antenna impedance / connector: | 50 ohm / Two SO-239 |
| Dimensions (W*H*D): | 216*70*222 mm (8.5*2.76*8.74") |
| Weight: | 2.04 Kg (4.5 lb) |
| Other features: |
CTCSS encoder. IF-DSP with 35 built-in filters. Full QSK.
Attenuator. NB. Transverter jack (+5 dBm output).
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Triple conversion superheterodyne
1st IF: 45 MHz
2nd IF: 450 KHz
3rd IF: 14.5 KHz
|
| Sensitivity: |
SSB/CW: 0.2 uV (10 dB S+N/N @ 2.4 KHz BW)
|
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 2 W at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| Pwr |
|---|
| 6 m: | 1-20 W |
| 2 m: | 1-20 W |
|
| Modulation system: | DSP |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | ? ohm / 4-pin (Metal locking ring connector) |
| Microphone input level: | ~5 mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | USA, 2000-200x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: |
QST: October 2001
|
| Options / Accessories: |
705
937
|
Desk microphone
Power supply. 13.8 VDC, 11 A
|
|
