| GENERAL |
| Type: | VHF receiver/scanner |
| Frequency range: |
76-82 / 164-172 MHz
|
| Tuning steps: | Channelized |
| Frequency stability: | ?% |
| Mode: | FM |
| Channels / memory management: |
8 regular
XTAL controlled
|
| Power supply: | 13.8 VDC (Male barrel jack, center positive) |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | 50-75 ohm / DIN41585 (Motorola) |
| Dimensions (W*H*D): | 118*42*164 mm (4.65*1.65*6.46") |
| Weight: | 785 g (1.73 lb), with mobile bracket |
| Other features: | |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 10.7 MHz
2nd IF: 455 KHz - Ceramic filter: Murata CFU455D
|
| Sensitivity: | |
| Selectivity: | 20 KHz (-6 dB)
40 KHz (-40 dB) |
| Image rejection: | |
| AF output power / speaker: | ? W at ?% distortion / 8 ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | 197x-197x (Discontinued) |
| Additional info: |
350-010 - Main board
350-020 - LED board
|
| Related documents: |
AF amplifier: M51513L
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
