| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
TX: 144-146 MHz
RX: 115-174 MHz
|
| Tuning steps: | ? KHz |
| Frequency stability: | ±? ppm |
| Mode: | TX: FM
RX:AM / FM |
| Channels / memory management: |
200 regular
|
| Repeater shift / offset: | ± |
| Power supply: | 4-15 VDC |
| Current drain / power consumption: | RX: ? mA
TX: ? A |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 58*122*27 mm (2.28*4.8*1.06") |
| Weight: | 300 g (10.58 oz) |
| Other features: |
CTCSS/PL encoder. A sliding door covers the keypad when not in use.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2 m: | 5 W | ? W | ? mW |
|
| Modulation system: | |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -? dB |
| Microphone impedance / connector: | ? ohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 199x-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
CNB181
CNB182
CNB183
CNB184
CTN181
|
NiCd battery pack. 4.8 V, 700 mAh
NiCd battery pack. 9.6 V, 600 mAh
NiCd battery pack. 6 V, 1100 mAh
NiCd battery pack. 6 V, 700 mAh
Tone squelch unit
|
|
