| GENERAL |
| Type: | Amateur VHF transceiver |
| Frequency range: |
Europe (General, E suffix)
TX: 144-148 MHz
RX: 136-160 MHz
Sweden (ES suffix)
TX: 144-146 MHz
RX: 136-160 MHz
|
| Tuning steps: | 5 / 10 / 12.5 / 15 / 20 / 25 / 30 / 50 / 100 KHz and 1 MHz |
| Frequency stability: | |
| Mode: | FM |
| Channels / memory management: |
100 regular with alpha tags (Seven characters)
1 call
! program scan pair
RAM storage with lithium battery backup
|
| Repeater shift / offset: | ±? |
| Power supply: | 4-15 VDC (Battery terminals)
or 4.5-16 VDC (External) |
| Current drain / power consumption: | RX: 12-30 mA (Squelched)
TX: Max 1.3 A |
| Antenna impedance / connector: | 50 ohm / BNC |
| Dimensions (W*H*D): | 58*100*26 mm (2.28*3.94*1.02"), without battery |
| Weight: | 290 g (10.2 oz), with battery and antenna |
| Other features: |
CTCSS/PL encoder. DTMF with paging. Dual watch. 1750 Hz call tone.
Tone scan with optional CTN115.
|
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Double conversion superheterodyne
1st IF: 21.8 MHz
2nd IF: 450 KHz
|
| Sensitivity: | 0.16 uV (12 dB SINAD) |
| Squelch sensitivity: | 0.1 uV (Threshold) |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 250 mW at 10% distortion / 8 ohm |
| External speaker connector: | |
|
|
|
|
| TRANSMITTER SECTION |
| RF output power: |
| High | Mid | Low |
|---|
| 2 m: | 1.8-5 W | 1.8-2.5 W | 350 mW |
NB! The high and mid output levels depend on voltage / battery pack.
|
| Modulation system: | Reactance modulation |
| Max FM deviation (Factory set): | ±5 KHz |
| Spurious emissions: | Better than -60 dB |
| Microphone impedance / connector: | 1.5 Kohm / ?-pin |
| Microphone input level: | ? mV |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1996-199x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
CAW-151B
CAW-152B
CBT-156
CHP-111
CHP-150
CLC-155
CLC-156
CLC-157
CMB-112
CMB-600
CMP-111
CMP-113
CMP-115
CNB-155
CNB-156
CNB-157
CNB-158
CSA-181AB
CSA-181EB
CTN-115
CWC-156A
CWC-156E
|
Base station power cable
Mobile power cable with noise filter
Battery case (Four AA alkaline or rechargeable batteries)
Headset with PTT
Headset with VOX
Soft case, for CNB-155 and 156
Soft case, for CNB-156
Soft case, for CNB-157 and 158
Mobile bracket
Helmet clip for CHP-150
Speaker-microphone
Speaker-microphone, tiepin type
Speaker-microphone, compact type
NiCd battery pack. Small size
NiCd battery pack. 6 V, 600 mAh
NiCd battery pack. 9.6 V, 600 mAh
Long-life NiCd battery pack
Desktop charger. 120 VAC
Desktop charger. 220 VAC
Tone squelch unit (CTCSS/PL decoder)
Wall charger. 120 VAC
Wall charger. 220 VAC
|
|
