| GENERAL |
| Type: | RDF receiver |
| Frequency range: |
| Beacon: | 0.15-0.4 MHz |
| Broadcast: | 0.54-1.6 MHz |
| Marine: | 1.6-5.0 MHz |
| VHF: | 148-174 MHz |
|
| Tuning steps: | Analog / continuous |
| Frequency stability: | ±? ppm |
| Mode: | AM / FM / SSB |
| Channels / memory management: |
2 optional (XTAL controlled)
|
| Power supply: | ? VDC |
| Current drain / power consumption: | Max ? mA |
| Built-in antennas: | Two telescopic whips
One motorized ferrite antenna |
| External antenna impedance / connector: | - |
| Dimensions (W*H*D): | ? mm (?") |
| Weight: | ? Kg (? lb) |
| Other features: | Automatic direction finder. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
? conversion superheterodyne
|
| Sensitivity: | |
| Squelch sensitivity: | |
| Noise figure: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | ? mW at ?% distortion / ? ohm |
| External speaker connector: | TS "Minijack" (3.5 mm) |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 197x-197x (Discontinued) |
| Additional info: | |
| Related documents: | |
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
|
