| GENERAL |
| Type: | HF/VHF receiver |
| Frequency range: |
Type 1
0.15-30 / 76-108 / 116-136 MHz
Type 2
0.15-26.1 / 87.5-108 MHz
Type 3
0.15-0.285 / 0.53-26.1 MHz
|
| Tuning steps: | AM: 100 Hz, 1 KHz
WFM: 50 KHz
AIR: 25 KHz |
| Frequency stability: | ? ppm |
| Mode: |
Type 1
AM / AM-Sync / SSB / CW / WFM
Type 2
AM / AM-Sync / WFM
Type 3
AM / AM-Sync
|
| Channels / memory management: |
32 regular
|
| Power supply: | 4.5 VDC (Three LR20 / D + two LR6 / AA batteries)
or 4.5 VDC external |
| Current drain / power consumption: | ? mA |
| Antenna impedance / connector: | ? ohm / External
- / Telescopic whip and ferrite rod |
| Dimensions (W*H*D): | 290*160*50 mm (11.42*6.3*1.97") |
| Weight: | 1.8 Kg (3.97 lb), with batteries |
| Other features: | 12/24 hr clock and timer. Attenuator. |
|
|
|
|
| RECEIVER SECTION |
| Receiver system: |
Single conversion superheterodyne (WFM)
IF: ? MHz
Double conversion superheterodyne (AM/SSB/CW)
1st IF: ? MHz
2nd IF: ? KHz
|
| Sensitivity: | |
| Selectivity: | |
| Image rejection: | |
| AF output power / speaker: | 380 mW at 10% distortion / ? ohm |
| External speaker connector: | |
|
|
|
|
| MISCELLANEOUS |
| Manufactured: | Japan, 1984-2003 (Discontinued) |
| Additional info: | |
| Related documents: |
User manual (8.1 MB)
Service manual (6.2 MB)
|
| Modifications and fixes: | |
| Reviews: | |
| Options / Accessories: |
AN-1
AN-3
DCC-127A
RK-69A
|
LW/MW/SW wide range antenna
VHF antenna
Car battery cord
Connecting cord
|
|
